WLE1216V5-20 4×4 Wave-2 802.11ac/a/n Mini PCIe WiFi Module

Description

4×4 Wave-2 802.11ac/a/n Mini PCIe WiFi Module

• Standard form factor
• Qualcomm Atheros “Cascade”™ QCA9984
• 5GHz max 20dBm output power (per chain)
• Heat sink allows free air operation
• IEEE 802.11ac compliant & backward compatible with 802.11a/n, up to 1733Mbps
• Multi-user MIMO (MU-MIMO) beamformer
• 4 spatial streams (4SS) at 80MHz
• 2 spatial streams (2SS) at 80+80MHz
• Mini PCI Express 2.0 interface
• Supports Spatial Multiplexing, Cyclic-Delay Diversity (CDD), Low-Density Parity Check (LDPC) Codes, Maximal Ratio Combining (MRC), Space Time Block Code (STBC)
• Supports IEEE 802.11d, e, h, i, j, k, r, u, v time stamp, w and z standards
• Supports Dynamic Frequency Selection (DFS)
• Designed for High Bandwidth Enterprise Wireless Access Points
