OVP Switch with Single Input, Dual Output Switches with Surge Protection and Individual Enables
Features
- Single Input, Dual Output Low On- Resistance Switch
- VBUS to OUT: typ. 23mΩ
- VBUS to SYS: typ. 30mΩ (Reverse Blocking)
- Wide Input Voltage Range: 2.7V – 28V
- VBUS Abs Max: 28V
- Surge and ESD Protected Input
- Surge Protection
- IEC61000-4-5: > ±100V
- ESD Protection
- IEC61000-4-2 (Level 4) VBUS
- Contact: ±8kV
- Air Gap: ±15kV
- HBM: 2kV All Pins
- IEC61000-4-2 (Level 4) VBUS
- Surge Protection
- Integrated Overvoltage Protection (OVP)
- VBUS to OUT: 5.95V
- VBUS to SYS: 5.25V
- Maximum Continuous Current
- VBUS to OUT: 3.5A
- VBUS to SYS: 6A
- Dual Enable Control with Independent Shutdown Control
- Active LOW VBUS to OUT
- Active HIGH VBUS to SYS
- Active HIGH Shutdown
- VBUS detection LDO
- VBUS to SYS FLAG
- Over Temperature Protection
- Pb-free 28-Bump, WLCSP 2.96mm x 1.67mm
- -40°C to 85°C Operating Temperature Range
Applications
- Smartphones and Tablets
- Mobile Internet Devices
- Wearables
- Portable Devices
Key Electrical Specifications
| Vin(Min) | Vin(Max) | ON Resistance | Max Current | OVP Trip Point | Package |
| 2.7V | 28V | 23/30mΩ | 3.3/5.0A | VBUS-OUT: 5.95V VBUS-SYS: 5.25V |
WLCSP-28 2.96 x 1.67mm |
