Maxtena M7HCT-A-SMA Active Multi Frequency Helical GNSS L1 L2 Antenna 30db

M7HCT-A-SMA active multi frequency helical GNSS L1 L2 antenna 30db. Covering the GPS, Glonass, Galileo and Beidou global navigation satellite systems (GNSS).

Maxtena’s M7HCT-A-SMA covers:
GPS L1 L2
GLONASS G1 G2
Galileo E1 E5B
Beidou B1 B2

M7HCT-A-SMA active multi frequency helical GNSS L1 L2 antenna 30db Features:
Multiband High Accuracy GNSS active rugged antenna designed for L1 / L2 GPS, Galileo, Beidou and GLONASS bands. L30C
Qaudrifilar helix antenna
Concurrent GNSS reception on L1: GPS, GLONASS, Galileo, Beidou and L2: GPS L2C, Galileo E5B, and GLONASS L3OC
Rugged IP-67 rating with SMA mount
Small form factor
Ground plane independent
GIS, RTK and other high accuracy GNSS applications
Low power consumption
Low phase center variation over azimuth and elevation and among different samples
Ultra lightweight – 25 grams
Automotive grade PCB housing

M7HCT-A-SMA is an active multi-frequency, high-accuracy, GNSS antenna for the L1/L2 GPS, Galileo, Beidou and GLONASS bands.

Maxtena M7HCT-A-SMA is a screw-on design, featuring an integrated SMA connector and is rated IP-67 when mounted for added protection.

Maxtena‘s M7HCT-A-SMA ideal for applications requiring minimal integration effort or for retrofitting existing products.
