YIC G-MOUSE-503 series MediaTek GPS GLONASS Receivers

The YIC G-MOUSE-503 series are MediaTek GPS GLONASS Receivers.

In this case they use the MediaTek MT3333, as a result they are able to track up to 99 channels. In addition to this they also provide a fast time to first fix.

Furthermore the antennas are compact, high performance and low power.

SKU: YIC-G-MOUSE-503F-GPS-GLN-1 Categories: , Brand:
Enquire Now

Product Documents

The YIC G-MOUSE-503 series are MediaTek GPS GLONASS Receivers.

In this case they use the MediaTek MT3333, as a result they are able to track up to 99 channels. In addition to this they also provide a fast time to first fix.

Furthermore the antennas are compact, high performance and low power.

The YIC G-MOUSE-503 series of GPS GLONASS Receivers have many features, in particular:
GNSS Chipset: MediaTek MT3333 (FLASH)
Frequency: GPS, GALILEO, QZSS: L1 1575.42MHz, GLONASS, SBAS L1, WAAS, EGNOS, MSAS
Channels: 99 channels
Input Voltage: 3.0 to 5.5V
Interface: UART/TTL, RS232 or USB
Memory Available: Flash or ROM

In addition to this, the are easy to install.

The following YIC G-MOUSE-503 series models are available:

Model Dimension Internal Memory VCC (V) Additional LNA/SAW PPS LED Display GNSS Chip Mount Interface
GT-503GG 55 x 46 x 14.5 mm FLASH 3.3 / 5 MT3333 Adhesive UART / TTL
GT-503MGG 55 x 46 x 14.5 mm FLASH 3.3 / 5 MT3333 Magnetic UART / TTL
GR-503 55 x 46 x 14.5 mm ROM 3.3 / 5 MT3337 Adhesive RS232
GR-503M 55 x 46 x 14.5 mm ROM 3.3 / 5 MT3337 Magnetic RS232
GT-503 55 x 46 x 14.5 mm ROM 3.3 / 5 MT3337 Adhesive UART / TTL
GT-503M 55 x 46 x 14.5 mm ROM 3.3 / 5 MT3337 Magnetic UART / TTL
GU-503 55 x 46 x 14.5 mm ROM 3.3 / 5 MT3337 Adhesive USB
GU-503M 55 x 46 x 14.5 mm ROM 3.3 / 5 MT3337 Magnetic USB

The YIC G-MOUSE-503 series of MediaTek GPS GLONASS receivers can ordinarily be used in applications such as automotive navigation, personal positioning, fleet management and marine navigation.
