Modbus LoRa Sensor Go-IoT WISKA WIRE RS485
The WISKA WIRE RS485 Modbus LoRa Sensor incorporates the latest technology for monitoring any Modbus RTU RS485 device in a single small 90x57x16mm DC-powered ABS housing.
The WISKA WIRE RS485 supports the LoRaWAN 1.0.3 standard. It is fully configurable via a Serial interface (and via downlinks if combined with the Go-IoT DINGO range of BACnet LoRaWAN BMS Gateways).
Currently supporting Carlo Gavazzi, Eastron, Schneider, Hiking, Rayleigh and other Energy Meters. Others are easily supported via population of an Excel spreadsheet which is converted by Go-IoT into a configuration file for downloading to the WISKA WIRE. Furthermore a payload decoder is then provided by Go-IoT for this configuration. Please enquire for further details.
Go-IoT Item Id: WISKA-WIRE-RS485
Wireless Technology – LoRaWAN® 1.0.3
Wireless Security – LoRaWAN® End-to-End encryption (AES-CTR), Data Integrity Protection (AES-CMAC)
LoRaWAN Device Type – Class A/C (configurable) End-device. (Class B is optional)
Supported LoRaWAN® features – OTAA, ABP, ADR, Adaptive Channel Setup
Supported LoRaWAN® regions EU433, CN470, IN865, EU868 (standard), AU915, US915, KR920, AS923 (Other Regions are optional)
Link Budget – 131 dB (SF5) to 151 dB (SF12)
RF Transmit Power – 14 dB / 22 dB (Region specific)
Antenna – Internal
DC Supply – 12-24V DC
LED Status – Blue (Power + Memory Boot Operating Status and LoRaWAN Join Process Attempt) / Green (LoRaWAN Join Process Successful / LoRaWAN Uplink)
Other PSU options – please enquire
Serial Interfaces – RS485 300 – 115200 Baud – 2 Wire (RS232 300 – 115200 Baud – 2 Wire available on request)
Case Style Edge – 90 x 57 x 16 mm DIN Rail or wall mount
Case Colour – UL94 – V0 Polycarbonate – Grey
For full data and more information regarding options please see the datasheet or use the contact form to enquire.
